轴径 | 连座轴承 型号 | 外形尺寸(mm) | 轴承型号 | 座型号 | 重量 (kg) | |||||||||
d | Ho | L | C | H | A | F | M | B | S | |||||
(min.) | (mm) | |||||||||||||
1/2
5/8
11/16 3/4 | 12
15
17
20 | UCHA201 201-8 202 202-10 203 203-11 204-12 204 | 96 | 64 | 0 | 64 | 40 | 19 | G3/4 | 31 | 12,7 | UC201 201-8 202 202-10 203 203-11 204-12 204 | HA204 | 0,73 |
7/8 15/16
1 |
25 | UCHA205-14 205-15 205 205-16 | 103 | 78 | 0 | 64 | 40 | 19 | G3/4 | 34 | 14,3 | UC205-14 205-15 205 205-16 | HA205 | 0,88 |
1-1/8
1-3/16 1-1/4 |
30 | UCHA206-18 206 206-19 206-20 | 103 | 78 | 0 | 64 | 40 | 19 | G3/4 | 38,1 | 15,9 | UC206-18 206 206-19 206-20 | HA206 | 1,0 |
1-1/4 1-5/16 1-3/8
1-7/16 |
35 | UCHA207-20 207-21 207-22 207 207-23 | 116 | 92 | 0 | 70 | 40 | 19 | G3/4 | 42,9 | 17,5 | UC207-20 207-21 207-22 207 207-23 | HA207 | 1,2 |
1-1/2 1-9/16 |
40 | UCHA208-24 208-25 208 | 121 | 96 | 2 | 73 | 40 | 19 | G3/4 | 49,2 | 19 | UC208-24 208-25 208 | HA208 | 1,3 |
1-5/8 1-11/16 1-3/4 |
45 | UCHA209-26 209-27 209-28 209 | 136 | 108 | 5 | 82 | 48 | 21 | G1 | 49,2 | 19 | UC209-26 209-27 209-28 209 | HA209 | 1,8 |
1-7/8 1-15/16
2 |
50 | UCHA210-30 210-31 210 210-32 | 140,5 | 115 | 5 | 83 | 48 | 21 | G1 | 51,6 | 19 | UC210-30 210-31 210 210-32 | HA210 | 2,1 |
2 2-1/8
2-3/16 |
55 | UCHA211-32 211-34 211 211-35 | 150 | 126 | 7 | 87 | 60 | 24 | G1-1/4 | 55,6 | 22,2 | UC211-32 211-34 211 211-35 | HA211 | 2,8 |
2-1/4
2-3/8 2-7/16 |
60 | UCHA212-36 212 212-38 212-39 | 173 | 142 | 9 | 102 | 60 | 28 | G1-1/4 | 65,1 | 25,4 | UC212-36 212 212-38 212-39 | HA212 | 3,9 |
2-1/2 |
65 | UCHA213-40 213 | 200 | 166 | 9,5 | 117 | 70 | 32 | G1-1/2 | 65,1 | 25,4 | UC213-40 213 | HA213 | 5,9 |
2-3/4 |
70 | UCHA214-44 214 | 200 | 166 | 9,5 | 117 | 70 | 32 | G1-1/2 | 74,6 | 30,2 | UC214-44 214 | HA214 | 5,9 |
2-15/16
3 |
75 | UCHA215-47 215 215-48 | 200 | 166 | 9,5 | 117 | 70 | 32 | G1-1/2 | 77,8 | 33,2 | UC215-47 215 215-48 | HA215 | 5,9 |
